LC-AVP-2-40A Smart Circuit Breaker
- 10-in-1 Digital Display – Voltage, current, power, frequency & more.
- 1.46″ HD TFT Color Screen – Clear, bright, and easy to read.
- WiFi Remote Control – App control with timer and cloud access.
- Standard DIN Rail Mount – Quick and easy installation.
- Compact & Easy to Wire – Space-saving, simple to install.
- Wide Applications – Ideal for homes, factories, offices, and distribution panels.
Product Overview & Applications:
Automatically disconnect the powersupply when the power supply leaks.
Technical Parameters
Product Specifications | |
| Operating voltage | AC80-300V |
| Frequency | 35/75Hz |
| Overvoltage range | 130-300V |
| Undervoltage range | 80-210V |
| Current range | 1-40A |
| Max rated current | 40A |
| Power-off delay range | 1-30S |
| Power failure recovery time range | 1-60S |
| Voltage correction value | -99-99V |
| Current correction value | -9.9-9.9A |
| Overcurrent power failure delay range | 1-30S |
