Product Overview & Applications:
Technical Parameters
| Power Supply | Output Type | Contact Type | 5mm Sensing Distance Model | 10mm Sensing Distance Model |
| DC 6~36V | NPN | NO | ALJ24A3-5-Z/N1 | ALJ24A3-10-Z/N1 |
| NC | ALJ24A3-5-Z/N2 | ALJ24A3-10-Z/N2 | ||
| NO+NC | ALJ24A3-5-Z/N3 | ALJ24A3-10-Z/N3 | ||
| PNP | NO | ALJ24A3-5-Z/P1 | ALJ24A3-10-Z/P1 | |
| NC | ALJ24A3-5-Z/P2 | ALJ24A3-10-Z/P2 | ||
| NO+NC | ALJ24A3-5-Z/P3 | ALJ24A3-10-Z/P3 | ||
| 2 wire | NO | ALJ24A3-5-Z/D1 | ALJ24A3-10-Z/D1 | |
| NC | ALJ24A3-5-Z/D2 | ALJ24A3-10-Z/D2 | ||
| AC 90~250V | 2 wire | NO | ALJ24A3-5-J/A1 | ALJ24A3-10-J/A1 |
| NC | ALJ24A3-5-J/A2 | ALJ24A3-10-J/A2 | ||
| NO+NC | ALJ24A3-5-J/A3 | ALJ24A3-10-J/A3 |
wiring diagram
