SDC15 DC Contactor Series
- 12V–120V Wide Voltage Support.
- 100A High Current Capacity.
- Compact & Durable Construction.
- CE Certified Safety.
- Reliable Performance for Industrial & EV Applications.
Product Overview & Applications:
Constructed with high-quality materials, capable of handling up to 100A, perfect for robust motor starter applications.
Technical Parameters
Product Specifications | |||
| Item | SDC15-100 / QCC15-100 | SDC15-200 / QCC15-200 | SDC15-300 / QCC15-300 |
| Contact Form | 1NO | ||
| Rated Current | 100A | 200A | 300A |
| Coil Voltage | 6V, 12V, 24V, 36V, 48V, 60V, 72V, 84V, 120V, 150V, 220V | ||
| Contact Voltage | ≤80V DC | ||
| Coil Power | 18–30W | ||
| Operate Time | 30ms | ||
| Release Time | 5ms | ||
| Electrical Life | 20,000 Cycles | ||
| Mechanical Life | 300,000 Cycles | ||
| Contact Material | AgCdO | ||
| Load Terminal | M8 Screw | ||
| Coil Terminal | M5 Screw / 6.3mm Insert | ||
| Ambient Temperature | -25°C ~ +70°C | ||
| Protection Class | IP40 | ||
| Certification | CE | ||
